- Size: 100
- Place of Origin: China
- Brand Name: MingYu Mortar Equipment CO., LTD
- Model Number: MY-20
- Weight: 30000.000 kg
Ready-mixed mortar production line, mainly by the raw material storage warehouse, batching system, to warehouse, elevator, the main mixer (3-6 cubic), automatic weighing packaging machine (adapted to the valve pocket), bulk system, dust collector and electric control system, etc.
Adapted to the normal dry mixing masonry mortar production (such as plastering mortar, masonry mortar flooring mortar, decorative mortar, waterproof mortar, etc.).
The mixer tank and parts are all made of special wear-resistant materials, particularly strong wear resistance, long service life, has the incomparable superiority of domestic similar products, occupy the leading position in the industry. The whole equipment stable performance, mixing materials, and has low energy consumption, less investment, quick effect, covers an area of small, simple operation, and many other advantages. Accordind to different configuration, can realize of 10-300000 tons Ready-mixed mortar.
This production line is mainly composed of the following equipment
1.Raw material storage tank:
Dry mortar production line used for storage of bulk materials such as cement, fly ash, sand. This case USES the domestic commonly used 50 tons or 100 tons of cement warehouse (client selection) as raw materials warehouse, generally USES cement, fly ash, sand three raw materials warehouse. Cement, fly ash using tanker loading, sand the bucket on the material.
2. Sand drying device:
Used to the wet sand drying, the system includes feeder, bucket machine, hot blast stove, dryers, sieve, dust, cooling, conveying, and improvement of equipment. Customers can choose according to actual situation sand making machine.
3. Ingredients device:
By the hopper JiLiangCheng, screw conveyor, discharging device, force sensing device, computer control system. Its according to different raw materials formula will automatic metering, reduce labor intensity and environmental pollution, and ensure the quality of dry mortar products.
4. The hybrid system:
The requirement of dry mortar mixer is: mixing, no dead angle, equipment wear, feeding speed. Our company use the biaxial zero gravity mixing machine as the main mixing machine. Mixing, high efficiency, short time. Host internal installation high manganese wear-resisting lining thickness up to 20 mm, long service life, easy to change.
5. Powder packing machine:
Dry mortar used in valve bag packaging machine is more, due to valve bag packaging without seam, as long as one operator. With advantages of high yield, high efficiency and reduce labor.
6. Dust collector:
Used for recovery of dry mortar production line in the dust, conducive to environmental protection. Dust mouth is located in the cement silos, hoist position such as feeding mouth, filling machine.
7. Transmission and improve the system:
Used in the production line of silo in conveying means has: horizontal and vertical transmission, horizontal conveyor can use screw conveyor, vertical conveyor generally adopts the bucket elevator, electric hoist may be adopted.
8. Automatic industrial control system by PLC industrial control, high electric cabinet, touch screen, computer, etc.
The current configuration to the construction site of mortar quality is not stable, strength can not meet the requirements, and dry mortar USES industrialized production, to strictly control the raw material and mixing ratio, to ensure the mortar quality is stable and reliable.
- Size: 100
- Place of Origin: China
- Brand Name: MingYu Mortar Equipment CO., LTD
- Model Number: MY-20
- Weight: 30000.000 kg
